ASRock H610M-HDV/M.2 R2.0

د.ل 850

د.ل 800

Digi Power : Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced. Ultra M.2 32Gb/s (PCIe Gen3 x4) The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DisplayPort + HDMI combo. *Supported only with processors with integrated graphics. HDMI 4k @60Hz Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.

CPU

CPU SocketSocket 1700
CPU BrandIntel
Installed Processors (Max)0 (1)
Supported Processor ManufacturerIntel
Supported Processors14th, 13th & 12th Gen Intel Core Processors
64-bit SupportYes
SocketLGA1700

Rear Panel I/O Ports

USB Ports2 x USB 3.0
4 x USB 2.0
DisplayPorts1 x DisplayPort 1.4
HDMI Port1 x HDMI 2.1
VGA Port1 x D-Sub
Keyboard/Mouse Combo Port1 x PS/2
RJ-45 Ports1 x RJ-45
Audio Line In Ports1 x 3.5mm Jack
Audio Line Out Ports1 x 3.5mm Jack
Microphone In Port1 x 3.5mm Jack

Internal I/O Connectors

SATA Connectors4 x SATA III
USB Connectors1 x USB 3.0 header (supports 2 ports)
1 x USB 2.0 header (supports 2 ports)
Speaker1 x Speaker header
Front Panel Connectors1 x Front Panel
1 x Front Audio
Cooling Fan Support1 x CPU fan header
1 x Chassis/Water Pump fan header
Chassis Intrusion Connector1 x Chassis Intrusion header
TPM Header1 x SPI TPM header
Power Connector Port1 x 24-pin ATX
1 x 8-pin EPS
Other Connectors1 x M.2 slot, Key M, Type 2242/2260/2280 (PCIe Gen3)

Memory

Memory Bus SpeedUp to 3200 MHz
Memory TypeDDR4
Maximum RAM64 GB
Memory Slot2 x DIMM

Motherboard

NorthbridgeIntel H610
RAID SupportedNo
SATA SupportedYes

Expansion

Number of PCI Express Slots1 x PCI Express 4.0 x16 slot
1 x PCI Express 3.0 x1 slot

Graphics Device

Integrated Graphics SupportedYes

Warranty

Warranty3 Years

Sound

Integrated SoundRealtek ALC897

Network

Integrated NetworkRealtek 8111H
Network Speeds SupportedUp to 1 Gbps
Wireless LANNo
BluetoothNo

System Requirements

Operating Systems SupportedMicrosoft Windows 11 Home

System

Software Included (may be trial or restricted)Yes
DriversYes

Physical

Form FactormATX Motherboard
In The BoxMotherboard
Quick Installation Guide
Support CD
I/O Shield
2 x SATA Cables
M.2 Screw
Width193 mm
Length220 mm

Key Features

RDIMM Memory SupportedNo
RDIMM Memory RequiredNo
Wireless NetworkNo
Motherboard Width193 mm
Motherboard Height220 mm
mSATA SupportedNo
U.2 SupportedNo
Main ColourBlack
Memory ChannelDual
On-board Audio Type7.1
Number of SATA Ports4 port(s)
Number of USB Ports6 port(s)
USB 3.0 SupportYes
Multi GPU SupportNo
VGA ConnectionYes
DVI ConnectionNo
HDMI ConnectionYes
DisplayPort ConnectionYes
Motherboard Form FactormATX
Motherboard (EPS) Power Connectors4+4-Pin
Motherboard ChipsetIntel H610
ThunderboltNo
Motherboard ModelASRock H610M-HDV M.2 R2.0
USB 3.1 SupportNo
Internal USB3.0 HeaderYes
M.2 SupportYes
On-board RGB ControlNone
RGB Header TypeNone
Addressable RGBNo
Internal USB Type-C HeaderNo
Power Requirement (auto)60 W
Max Memory Speed Supported (Non-overclocked)3200 MT/s
CPU Power Pins (female)8
Total M.2 Slots1
Maximum NVMe M.2 ports1
SATA ports4
No. of front USB2.0 ports supported2
No. of front USB3.0 ports supported2
