| Nominal Voltage | 12V |
| Nominal Capacity (20HR) | 150AH |
| Dimensions | Length: 522 ± 3mm Width: 240 ± 3mm Container Height: 218 ± 3mm Total Height (with Terminal): 224 ± 3mm |
| Terminal | T11 |
| Container Material | ABS |
| Max. Discharge Current | 1500A (5s) |
| Internal Resistance | Approx. 3.5mΩ |
| Operating Temp. Range | Discharge: -15~50°C (5~122°F) Charge: 0~40°C (32~104°F) Storage: -15~40°C (5~104°F) |
| Nominal Operating Temp. Range | 25±3°C (77 ± 5°F) |
| Applications | Uninterruptable Power Supply (UPS) Electric Power System (EPS) Aircraft Signal Electronic apparatus and equipment Emergency backup power supply DC power supply |
