| Nominal Voltage | 12V |
|---|---|
| Nominal Capacity(20HR) | 200.0AH |
| Dimensions | Length : 522±3mm (20.55 inches) Width : 240±3mm (9.45 inches) Container Height : 218±3mm (8.58 inches) Total Height (with Terminal) : 224.5±3mm (8.81 inches) |
| Approx Weight | Approx 60.4 kg (133.2lbs) |
| Terminal | T11 |
| Container Material | ABS |
| Rated Capacity | 206.0 AH/10.3A (20hr ,1.80V/cell,25°C/77°F) 200.0 AH/20.0A (10hr,1.80V/cell,25°C/77°F) 170.0 AH/34.0A (5hr,1.75V/cell,25°C/77°F) 147.6 AH/49.2A (3hr,1.75V/cell,25°C/77°F) 119.4 AH/119.4A (1hr,1.60V/cell,25°C/77°F) |
| Max. Discharge Current | 2000A (5s) |
| Internal Resistance | Approx 2.9m Ω |
| Operating Temp.Range | Discharge : -15～50°C (5～122°F) Charge : 0～40°C (32～104°F) Storage : -15～40°C (5～104°F) |
| Nominal Operating Temp. Range | 25±3°C (77±5°F ) |
| Cycle Use | Initial Charging Current less than 30.0A.Voltage 14.4V~15.0V at 25°C(77°F) Temp. Coefficient -30mV/°C |
| Standby Use | No limit on Initial Charging Current Voltage 13.5V~13.8V at 25°C (77°F) Temp. Coefficient -20mV/°C |
| Capacity affected by Temperature | 40°C (104°F) 103% 25°C (77°F) 100% 0°C (32°F) 86% |
| Self Discharge | Leoch LP series batteries may be stored for up to 9 months at 25° C (77°F) and then a freshening charge is required.For higher temperatures the time interval will be shorter. |
