Microtek UPS ONLINE 2KVA/72V (1PH:1PH) (IB)

د.ل 4,100

Microtek offers Wide Range of High Frequency MAX LiFe Series (1PH IN – 1 PH OUT) IGBT Technology Based Online UPS from 1KVA to 30KVA based on World’s Latest Technology to meet the harsh Environmental and worst Power Conditions for Applications from Small Office requirement to Space Critical Missions with wide variety of Backup Range from 5 minutes to 10 hours to meet the needs of every individual.



OUTPUT

OUTPUT VOLATGE RANGE

 208 / 220 / 230 / 240 V AC

FREQUENCY RANGE (Synchronized Range)
FREQUENCY RANGE (Battery Mode)

 47 ~ 53 Hz or 57 ~ 63 Hz
 50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz

THD (Linear Load)

 ≤2%

THD (Non Linear Load)

 ≤4%

OVERLOAD

 >110%, 30s turn to Bypass Mode
 >150% instant turn to Bypass

CREST FECTOR

 3:1 (Max)

SHORT CIRCUIT PROTECTION

 5 cycles turn Off Inverter, no transfer to Bypass, provide Alarm (AC Mode), 5 cycles turn Off Inverter, provide Alarm(Battery Mode), Input Fuse blown or Breaker action

WAVEFORM

 Pure Sinewave

TRANSFER TIME
(AC Mode to Battery Mode)
(Inverter to Bypass)

 ZERO
 <4 ms

EFFECIENCY

 85%~ 92%



BATTERY

DC VOLTAGE

 72 V(7 AH* 6 Nos. Battery inside)

CHARGE CURRENT

 1.5 Amps

COMMUNICATION INTERFACE

 RS232,SNMP (Optional)

INDICATION

 LCD Display

NOISE LEVAL

 Less than 50dBA @ 1 Meter (With Fan Speed Control)

UPS OVERLOAD / UPS SHORT CIRCUIT

 110% / 300%

WARRANTY

 Two Years on Electronics & One Year on Battery

INPUT

MODEL

 NM72MX2KK11-IB

RATED CAPACITY

 2 KVA / 1800 Watts

INPUT VOLTAGE RANGE (Load <50%)

 118 ~ 295 V (± 5 V)

INPUT VOLTAGE RANGE (Load >50%)

 160 ~ 295 V (± 5 V)

FREQUENCY

 40 ~ 70 Hz

PHASE

 Single Phase with Ground

POWER FACTOR

 ≥ 0.99 @ full load
