SPECIFICATIONS
Model Name MAG Z590 TOMAHAWK WIFI
CPU Support Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel®
Core™ Processors, Pentium® Gold and Celeron® Processors
CPU Socket LGA 1200
Chipset Intel® Z590 Chipset
Graphics
Interface
1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x16 slot
Support 2-way AMD® CrossFire™ Technology
Display Interface Support 4K@60Hz as specified in HDMI™ 2.0b, DisplayPort
1.4
– Requires Processor Graphics
Memory Support 4 DIMMs, Dual Channel DDR4-5333 (OC)
Expansion Slots 2x PCIe 3.0 x1 slots
Storage 1x M.2 Gen4 x4 64Gb/s slot, 2x M.2 Gen3 x4 32Gb/s slots,
Support Intel® Optane™ Technology,
6x SATA 6Gb/s ports
USB ports 1x USB 3.2 Gen 2x2 20Gbps (Type-C),
2x USB 3.2 Gen 2 10Gbps (Type-A + Type-C),
6x USB 3.2 Gen 1 5Gbps (Type-A),
6x USB 2.0
LAN Intel® I225-V 2.5G LAN
WiFi / BT Intel® Wi-Fi 6E AX210, Bluetooth 5.2
Audio 8-Channel (7.1) HD Audio with Audio Boost 5
CONNECTIONS
1. DisplayPort
3. USB 3.2 Gen 1 5Gbps Type-A
5. Wi-Fi / Bluetooth Antenna
7. HDMI™
9. USB 3.2 Gen 1 5Gbps Type-A
11. USB 3.2 Gen 2x2 20Gbps Type-C
2. USB 2.0
4. 2.5G LAN Port
6. HD Audio Connectors
8. Flash BIOS Button
10. USB 3.2 Gen 2 10Gbps Type-A
12. Optical S/PDIF OUT
