PERFORMANCE |
Processor | Intel® Core™ i7-13700H, 14C (6P + 8E) / 20T, P-core 2.4 / 5.0GHz, E-core 1.8 / 3.7GHz, 24MB |
Graphics |
| Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics |
Chipset | Intel® SoC Platform |
Memory | 1x 8GB SO-DIMM DDR5-5200 |
Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
Max Memory |
| Up to 64GB DDR5-5200 |
Storage | 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
Storage Support |
| Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 2TB |
Storage Slot | Two M.2 2280 PCIe® 4.0 x4 slots |
Card Reader | SD Card Reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audio™ |
Camera | HD 720p with Privacy Shutter |
Microphone | 2x, Array |
Battery | Integrated 71Wh |
Power Adapter | 100W USB-C® Slim (3-pin) |
Special Features | Modern Standby |
DESIGN |
Display |
| 16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC |
Touchscreen | None |
Keyboard | Non-backlit, Arabic |
Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
Case Color | Arctic Grey |
Surface Treatment | Anodizing Sandblasting |
Case Material | Aluminium (Top), PC-ABS (Bottom) |
Dimensions (WxDxH) |
| 356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches) |
Weight |
| Starting at 1.7 kg (3.75 lbs) |
SOFTWARE |
Operating System | None |
Bundled Software | None |
CONNECTIVITY |
Ethernet | 100/1000M (RJ-45) |
WLAN + Bluetooth |
| Wi-Fi® 6, 802.11ax 2x2 + BT5.2 |
Standard Ports | - 1x USB 3.2 Gen 1
- 1x USB 3.2 Gen 1 (Always On)
- 1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
- 1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x SD card reader
|
Docking | |
Security Chip | Firmware TPM 2.0 Enabled |
Fingerprint Reader | Touch Style, Integrated in Power Button |
Physical Locks | Kensington® Nano Security Slot™, 2.5 x 6 mm |
Other Security | Camera privacy shutter |
