OUTPUT | |
OUTPUT VOLATGE RANGE | 208 / 220 / 230 / 240 V AC |
FREQUENCY RANGE (Synchronized Range) | 47 ~ 53 Hz or 57 ~ 63 Hz |
THD (Linear Load) | ≤2% |
THD (Non Linear Load) | ≤4% |
OVERLOAD | >110%, 30s turn to Bypass Mode |
CREST FECTOR | 3:1 (Max) |
SHORT CIRCUIT PROTECTION | 5 cycles turn Off Inverter, no transfer to Bypass, provide Alarm (AC Mode), 5 cycles turn Off Inverter, provide Alarm(Battery Mode), Input Fuse blown or Breaker action |
WAVEFORM | Pure Sinewave |
TRANSFER TIME | ZERO |
EFFECIENCY | 85%~ 92% |
BATTERY | |
DC VOLTAGE | 36 V(7 AH* 3 Nos. Battery inside) |
CHARGE CURRENT | 0.7 ~ 0.8 Amps |
COMMUNICATION INTERFACE | RS232,SNMP (Optional) |
INDICATION | LCD Display |
NOISE LEVAL | Less than 50dBA @ 1 Meter (With Fan Speed Control) |
UPS OVERLOAD / UPS SHORT CIRCUIT | 110% / 300% |
WARRANTY | Two Years on Electronics & One Year on Battery |
INPUT | |
MODEL | NM36MX1KK11-IB |
RATED CAPACITY | 1 KVA / 900 Watts |
INPUT VOLTAGE RANGE (Load <50%) | 118 ~ 295 V (± 5 V) |
INPUT VOLTAGE RANGE (Load >50%) | 160 ~ 295 V (± 5 V) |
FREQUENCY | 40 ~ 70 Hz |
PHASE | Single Phase with Ground |
POWER FACTOR | ≥ 0.99 @ full load |
